20kW Wall-mounted DC Fast Charging Station

Application

The new type 20kW wall-mounted DC fast EV Charger is manufactured by Uni Industry Group Co., Ltd. which is a R & D, manufacturing and service-oriented High-technology enterprise focusing on providing overall power automation solutions and new energy electric vehicle applications.
Uni’s new energy products and its services include: EV charging piles ie. EV chargers, PV storage and charging stations, EV charging station software service management platform, and the overall solution for the design, investment, construction and operation of the development, PV storage and EV charging stations.
At present, the company’s products are shipped and sold in Asia, Africa and Latin America, North America, Europe, Oceania, etc.

Specifications

Parameter

Input	Rated Voltage	400V AC
	Rated Current	50A
	Frequency	50/60Hz
Output	Output Voltage	200~750V DC	150~500V DC
	Maximum Current	33A	50A
	Rated Power	20KW	20KW
User Interface	Charge Connector	CCS2 cable
	Cable Length	7M
	Enclosure	Galvanized steel
	LED Indicator	Green/Red
	LCD Display	2.7” black & white screen
	RFID Reader	Mifare ISO/IEC 14443 A
	Start Mode	Plug&Play/RFID card
	Emergency Stop	Yes
Sefety	Energy Meter	No
	RCD	No
	Ingress Protection	IP54
	Impact Protection	IK08
	Electrical Protection	Over current protection, Short circuit protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection
	Certification	CE
	Certification Standard	EN/IEC 61851-1: 2017, EN/IEC 61851-23: 2014
	Warranty	2 Years
Environment	Installation	Wall-mount
	Cooling Method	Fan cooling
	Noise	≤60dB
	Work Temperature	-30℃~+50℃
	Work Humidity	5%~95%
	Work Altitude	<2000M
Package	Product Dimension	566426163MM (HWD)
	Package Dimension	730500420MM (LWH)
	Net Weight	30KG
	Gross Weight	34KG
	External Package	Carton
